Histogram is a image diagnostic rather than an image effect. When you apply the Histogram effect color levels are calculated and returned via the settings. The image is unaffected.




Settings

Name   Default   Description
Red "" A histogram of red levels as a comma delimited string.

Green "" A histogram of green levels as a comma delimited string.

Blue "" A histogram of blue levels as a comma delimited string.

RGB "" A histogram of RGB levels as a comma delimited string.

How it Works




Image histograms show how color levels are distributed within an image. Each color channel has a value between 0 and 255 and the histogram simply returns the number of pixels with each of these values. A light image will have many values at the higher end of the histogram while a dark one will have many values at the lower end.

After the Histogram effect has been applied to an image the settings contain the histograms of each of the color channels and also of a combined RGB channel. These values are held as comma delimited strings.


Example



The following example images show the effect of Histogram.






Original Image


Histogram of Red Intensities

Histogram of Green Intensities

Histogram of Blue Intensities

Histogram of RGB Intensities

Note that the photograph is unbalanced with little color at the dark end of the spectrum.

The actual values held in each of the settings and used to produce these graphs are given below.

Red = "0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,1,2,1,1,2,1,1,2,2,3,9,9,19,14,25,
26,32,48,47,92,101,140,190,251,372,455,580,883,1304,1442,3397,2252,3638,5184,3402,
3244,2442,2754,2177,2217,1603,1776,1258,1273,1169,1030,1071,1009,953,1005,1005,
971,1002,998,"

Green = "0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,1,0,0,0,2,1,5,5,5,7,15,30,40,75,167,
208,794,550,1373,969,1640,2007,1857,1907,4072,2507, 1964,2528,1616,1844,1384,1111,
1027,901,1006,1013,886,812,699,736,761,804,672,753,625,689,705,626,657,783,630,780,
692,791,719,666"

Blue = "0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,1,1,1,1,0,0,3,4,7,9,
14,23,41,57,85,126,182,257,348,905,622,1711,1013,1940,1183,1438,2258,1481,3128,1837,
2640,4221,2013,2266,1618,1941,1207,1300,932,1020,840,890,784,801,742,757,873,749,797"

RGB = "0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,1,1,2,2,2,2,5,10,14,26,59,72,271,188,
466,332,558,687,637,671,1398,896,737,954,704,827,740,780,1078,988,2038,1426,2154,2393,
1846,2079,1561,2228,1562,1870,2149,1492,1409,1172,1255,1006,1000,907,888,878,871,807"
